# Updating the firmware

Adapter firmware files are named `bitlink-adapter-<version>b<build>.bin`, for example `bitlink-adapter-1.0.1b412.bin`. Dongle files do not work on the adapter.

## From the WebUI

You need Chrome or Edge on a computer, and a USB-C cable.

1. Connect to the adapter in the WebUI and select **Config > System > Firmware Update > Update**.
2. Choose the firmware file and select **Restart into update mode**.
3. Connect the adapter to the computer with a USB-C cable.
4. Select **Select device and flash** and choose **BitLink Pad DFU**.
5. Wait for **Complete**. The adapter restarts with the new firmware.

<figure><img src="https://1477031042-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FrOZt2G56IoPRZNZUgGRS%2Fuploads%2Fgit-blob-ca329c1a27b0c492171ae8c68e32b30ae42c15be%2Ffirmware-step1.png?alt=media" alt="Firmware Update step 1, choose firmware" width="416"><figcaption><p>Step 2: choose the file</p></figcaption></figure>

## With dfu-util

1. Start update mode. See [Update mode and recovery](/manuals/bitlink-dc-adapter/firmware/recovery.md).
2. Run `dfu-util -a 0 -D bitlink-adapter-1.0.1b412.bin`.

{% hint style="info" %}
Do not disconnect the adapter while it is writing. If an update is interrupted, see [Update mode and recovery](/manuals/bitlink-dc-adapter/firmware/recovery.md).
{% endhint %}

No driver is needed on Windows. The current version is shown on the WebUI **Connect** page.


---
